جزئیات محصول
محل منبع: هانگژو، چین
نام تجاری: Zoyo
گواهی: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
شماره مدل: ZY006901
شرایط پرداخت و حمل و نقل
مقدار حداقل تعداد سفارش: MOQ انعطاف پذیر
قیمت: $2~$500 per piece
جزئیات بسته بندی: سفارشی
زمان تحویل: 3-4 هفته
شرایط پرداخت: L/C، D/A، D/P، T/T، Western Union، MoneyGram
قابلیت ارائه: 5 تا 20 هزار قطعه در روز
اندازه (اینچ): |
0.69 |
قطعنامه: |
96*16 |
منطقه فعال ((ملی متر): |
17.60 * 3.18 |
دمای کار: |
-40 تا 70 ℃ |
اندازه (اینچ): |
0.69 |
قطعنامه: |
96*16 |
منطقه فعال ((ملی متر): |
17.60 * 3.18 |
دمای کار: |
-40 تا 70 ℃ |
| GENERAL SPECIFICATIONS | ||||
| Item | Specification | Unit | Note | |
| Screen Size | 0.69 | |||
| Resolution | 96*16 | pixels | ||
| Operating Temperature | ‐40℃~70℃ | |||
| Storage Temperature | ‐40℃~85℃ | |||
| Module Size | Horizontal (H) | 26.30 | mm | typ |
| Vertical (V) | 8.00 | |||
| Thickness (T) | 1.2 | |||
| Active Area | Horizontal | 17.60 | mm | |
| Vertical | 3.18 | |||
| Interface Type | I2C | |||
| Application | Smart bracelet, ETC, electronic cigarette | |||
| Kind Tips: More details please contact us for products' specifications | ||||
The difference between PMOLED and AMOLED
| Feature | PMOLED | AMOLED |
| Matrix Type | Passive Matrix | Active Matrix |
| Control Mechanism | Sequential control of rows/columns | Individual pixel control via TFTs |
| Resolution | Lower | Higher |
| Brightness/Contrast | Good, but less uniform | Superior brightness and contrast |
| Refresh Rate | Lower, potential flickering | Higher, suitable for dynamic content |
| Power Consumption | Higher for larger/bright content | More efficient, especially with dark content |
| Complexity/Cost | Simpler, cheaper | More complex, more expensive |
| Typical Applications | Small, simple displays | High-end, high-resolution displays |
